02 — BIOS & Firmware

Recommended Modded BIOS

Stock P3.00 already includes standard fan control and IOMMU toggle — _fanoush_ confirmed this on a pristine P3.00 board. The modded P3.00 adds the chipset menu (Unlock Cache, ReBAR) but the stock BIOS already covers cooling and IOMMU needs.

P4.00 was discovered by faithy2386 in May 2026 — it's an undocumented stock BIOS version found on some boards. It is unstable (all 3D applications crash). Dumping and flashing to modified P5.00 fixes the issue (after CMOS clear). P4.00 is NOT recommended. P5.00 has more settings but also settings that can brick the board (rocksalt_). Some SMU commands differ on P5.00 and fewer people have looked at it (pops1cl). Patched P5 is "a bit of a mess" (kilrah).

P5.00 chipset lanes (snodrat, May 2026): Patched P5.00 exposes chipset PCIe lane configuration. Default mode is x2 (for M.2) + x1 + x1 (for Ethernet/USB). Alternate mode x1x1x1x1 splits the chipset lanes 4 ways. This enables potential use of Intel H10 Optane drives (requires M.2 carrier PCB) at PCIe 2.0 x1 per lane. Without the bifurcation, H10 drives only show their QLC side (snodrat).

Credits: P3.00 mod by Segfault. P5.00_clv is community-maintained. P4.00 discovery by faithy2386. elektricM credits Segfault for reverse engineering and maintaining modified firmware images.

Where to Download

BIOS Configuration (After Flashing)

Enter BIOS by spamming Delete on boot, then set:

Chipset → GFX Configuration:
  Integrated Graphics Controller = [Forces]
  UMA Mode                       = [UMA_SPECIFIED]
  UMA Frame Buffer Size          = [512M] ← See VRAM options below

Advanced → CPU Configuration:
  IOMMU = [Disabled]  ← MUST disable — broken on BC-250

Boot → Boot Mode:
  Boot Mode = [UEFI]

VRAM Allocation Options

Override for Full 16 GB Access (Advanced)

# Kernel parameters to access full shared memory:
amdgpu.gttsize=14750 ttm.pages_limit=3959290 ttm.page_pool_size=3959290

Source: elektricM vram.md — Advanced kernel parameters section.

Memory Timing Configuration Tool (bc250_memcfg)

Project: fanoush/bc250_memcfg ↗

Status: Working — compiled binary available. Works with stock P3.00 and P5.00 BIOS.

Sets CMOS BIOS memory configuration from Linux without rebooting into BIOS. The most useful parameter is UMA_SIZE (VRAM allocation), but it can also adjust memory timings. Pre-built binary available in the GitHub releases page (fanoush, Jul 2026).

Flashing Methods

Method 1: USB Flashing (EFI Shell — Recommended)

Files needed:

Steps:

1. Format USB drive to FAT32

2. Extract 4U12G BIOS Update.zip → copy BIOS EFI folder contents to USB root

3. USB root should contain: AfuEfix64.efi, Flash.nsh, amdvbflash.efi, Robin5.00, EFI/

4. Rename BC250_3.00_CHIPSETMENU.ROM → Robin5.00 (capital R, no extension)

5. Or edit Flash.nsh to point to your filename

6. Unplug all drives and SSDs (forces EFI Shell boot), insert USB, power on

7. At the yellow Shell> prompt, type blk0: (with a space after the colon) then Enter

8. Type Flash.nsh then Enter. Note: some keyboard layouts may cause typos (e.g., French keyboards type Flqsh.nsh) -- najibc, help-thread. If it fails, wait a few minutes and try again.

9. WAIT. Do NOT interrupt. If the flash appears to hang, wait at least 15 minutes.

10. System will reboot — power off immediately, remove USB stick

11. Clear CMOS (see below)

Method 2: Hardware Programmer (For Bricked/Recovery Boards)

# Backup first!
sudo flashrom -p ch347_spi -r backup_stock.bin
sudo flashrom -p ch347_spi -v backup_stock.bin
# Flash modded BIOS
sudo flashrom -p ch347_spi -w BC250_3.00_CHIPSETMENU.ROM

Method 3: Internal Flash from Linux [confirmed: elektricM docs]

# Backup first!
sudo flashrom -p internal -r backup.bin
sudo flashrom -p internal -w BC250_3.00_CHIPSETMENU.ROM

Method 4: UEFI Interactive Flashing Script

Project: Forbidden-Darkness/AMD-BC-250-UEFI-v2.2-Firmware-Menu-Script ↗

Bash script providing an interactive text menu that automates firmware backup and flashing. Backs up your existing BIOS before flashing the modded P3.00 firmware. Themed menus available (CachyOS, Bazzite, PS5Linux, etc.). Screenshots confirmed working (Forbidden-Darkness, Jul 2026). Useful for users who want a guided flashing experience without manual EFI shell commands.

⛔ CMOS Clear (Critical — Do Not Skip)

After any BIOS flash, settings will NOT persist unless CMOS is cleared:

Option A: Remove Battery (Recommended)

1. Power off, unplug PSU

2. Remove CR2032 battery for at least 60 seconds

3. While battery out, press power button 5 times to discharge capacitors

4. Reinsert battery, power on, enter BIOS

5. Verify CMOS was cleared (system clock should be wrong)

6. Reconfigure BIOS → F10 to save

Option B: CMOS Jumper

1. Power off, unplug PSU

2. Locate CMOS clear jumper (CLRCMOS1)

3. Move jumper to clear position (pins 2-3) for 20 seconds

4. Return jumper to default position (pins 1-2)

5. Power on and reconfigure BIOS

Flash Chip Identification

The BC-250 has two SPI flash chips — flash the correct one!

Key board components:

Source: elektricM pinouts.md — all entries verified.

USB Flashable BIOS Tool (Kenavru)

An alternative EFI flasher by kenavru ↗ eliminates the need for hardware flashing on many boards:

git clone https://github.com/kenavru/BC-250.git
cd BC-250
# Follow README for usage

40 CU Unlock (Re-Enable Harvested CUs)

Project: duggasco/bc250-40cu-unlock ↗

Status: Working (May 2026). 1.61x compute scaling verified. Two unlock methods available.

The BC-250 ships with 24 of 40 RDNA2 CUs active. 16 are harvested — disabled by firmware policy, not silicon defects. The harvested CUs have power, clocks, and matching CGTS config. Non-permanent — reboot without the modprobe config returns to stock 24 CUs. Guarded to only fire on BC-250 (PCI ID 0x13FE).

Also confirmed working on PS5 Linux (gennro, forwarded from PS5 Linux Discord, May 2026).

How It Works

Two registers control CU availability — both must be modified together:

Neither alone is sufficient. CC alone changes driver reporting but SPI still dispatches to 24 CUs. SPI alone enables dispatch but driver only generates work for 24 CUs. The patch writes both during amdgpu driver init (duggasco, scallion_9883). On Vangogh, the equivalent is SMU_MSG_RequestActiveWgp. On Cyan Skillfish, that SMU message isn't exposed but the SPI register is directly writable (Claude/Codex analysis).

Performance

Recommended sweet spot: 1500 MHz / 900 mV via cyan-skillfish-governor.

Method 1: No Kernel Patch (Recommended — big_trov, May 2026)

The latest discovery: the module can be patched on stock kernel without rebuilding the entire kernel. big_trov's runtime_40cu_unlock.sh and gennro's toolkit both use this approach. corbanitevevo confirmed identical results to patched kernel at 2200 MHz/1030 mV.

gennro/bc250-toolkit (CachyOS — Automated):

curl -sSLO https://raw.githubusercontent.com/gennro/bc250-toolkit/main/bc250-toolkit.sh
sudo bash bc250-toolkit.sh

Automates: kernel source download, amdgpu module patching, modprobe config, and hook for kernel updates. Supports stock, deckify, and bore CachyOS kernels. Works with limine and systemd-boot (gennro, hojnikb).

big_trov runtime script (Any Distro): See the bc250-collective Discord ↗ project-forums for the latest runtime_40cu_unlock.sh — the script URL changes with updates.

Method 2: Kernel Patch (All Distros — Fallback)

For distros without kernel-manager-based workflows, the original kernel-patch method still works:

cd /path/to/linux-source/drivers/gpu/drm/amd/amdgpu/
curl -O https://raw.githubusercontent.com/duggasco/bc250-40cu-unlock/main/patch/bc250-40cu-amdgpu.patch
patch -p5 < bc250-40cu-amdgpu.patch

make -C /lib/modules/$(uname -r)/build M=$(pwd) -j$(nproc) modules
sudo cp amdgpu.ko.zst /lib/modules/$(uname -r)/kernel/drivers/gpu/drm/amd/amdgpu/
sudo depmod -a
echo 'options amdgpu bc250_cc_write_mode=3' | sudo tee /etc/modprobe.d/bc250-40cu.conf
sudo reboot

Distro-specific instructions (CachyOS PKGBUILD patch, Bazzite COPR kernel, Arch AUR): see 05-OS Installation.

Bazzite: erewego posted pre-built RPMs against ba29 Deck kernel. Bazzite Desktop uses OGC kernel — kernel packages not yet available as of June 2026. Check the bc250-resources Discord channel for updated RPMs.

Verification

dmesg | grep active_cu_number     # Expected: active_cu_number 40
dmesg | grep bc250-40cu           # Shows register writes
RADV_DEBUG=info vulkaninfo --summary 2>&1 | grep num_cu   # Expected: num_cu = 40

bc250-cu-live-manager (No Kernel Patch Required — May 2026)

Project: WinnieLV/bc250-cu-live-manager ↗

Status: Working (May 2026). Interactive TUI for toggling CUs live — no kernel patch, no reboot needed.

Key features:

git clone https://github.com/WinnieLV/bc250-cu-live-manager.git
cd bc250-cu-live-manager
# Follow README instructions for your distro

This replaces the kernel patch method for most users. Use your distro's stock kernel + the live manager. After unlocking, verify with: sudo cat /sys/kernel/debug/dri/0/amdgpu_gca_config | grep active_cu_number (note: will still show 24 because the driver initialized with 24; UMR sets registers after init — big_trov).

June 2026 update: The live-manager now supports disabling stock WGPs (Work Group Processors), not just unlocking harvested CUs. This enables binary search for defective CUs — disable half, test, halve again until the bad CU is isolated (technique by pops1cl). See 10 — Troubleshooting for the full artifact hunting workflow.

CU Health Testing

Not all CUs are healthy. Bad CUs cause immediate artifacts (green dots, visual corruption) and shutdown when enabled (koloses, meee). Some users can only identify bad CUs via in-game artifacts, not synthetic benchmarks — a board that passes Furmark may still crash in games (pm_me_kitsunemimi). The live manager makes testing much faster — toggle CUs without rebooting and spot visual artifacts immediately.

Boards with scattered harvest patterns (■■□□■■□□■■) likely have defective silicon.

Live-manager method (TUI): Enable WGPs one by one in the interactive UI and check for artifacts immediately — no reboot needed.

cd bc250-cu-live-manager
sudo ./bc250-cu-live-manager.sh
# Press 'e' to edit WGP table, toggle unlocked WGPs, test stability
# Press 'f' for full 40 CU dispatch

Batch method (duggasco scripts): Per-WGP isolation test that reboots for each WGP. More thorough but much slower.

git clone https://github.com/duggasco/bc250-40cu-unlock.git
cd bc250-40cu-unlock
sudo ./scripts/bc250-cu-health-test.sh start   # 20 reboots, tests each WGP
./scripts/bc250-compute-verify.sh               # quick check, no reboot

CU Fault Detection

Doom: The Dark Ages and CS2 are more sensitive than synthetic benchmarks for detecting borderline CU faults. A board that passes Furmark may still crash in these games with unlocked CUs (community reports, May 2026).

CU Harvest Map

Check which CUs are active/harvested on your board using the duggasco/bc250-40cu-unlock ↗ scripts (sinh_28065, lux.the.cook):

git clone https://github.com/duggasco/bc250-40cu-unlock.git
cd bc250-40cu-unlock
./scripts/cu_map.sh                              # Show current CU map
./scripts/cu_map.sh --health results.tsv         # Show map with health overlay
./scripts/bc250-cu-mask.sh --results results.tsv # Generate selective mask config

Most boards show the standard 24/40 map (first 6 CUs of each block active). Some users confirmed full 40/40 (dizzey0709, lux.the.cook). ungamead confirmed 38/40 (2 harvested in SE1 SH1).

YMMV on stability: nonu0038 tested 3 boards, only 1 ran stable with all 40 CUs. The other 2 had artifacts/crashes. If your board has an irregular harvest map (e.g., ■■□□■■□□■■ pattern), the non-stock CUs are more likely to be defective. Selective masking lets you find a stable subset.

Selective CU Masking

Important: amdgpu.disable_cu=X.Y.Z indexes WGP pairs, not individual CUs (ungamead, greatapo, itsanarse). X.Y.Z = SE.SH.WGP-pair. Example: 1.1.1 disables WGP pair 1 on SE1 SH1 (CUs 3-4 there, NOT CUs 1-2).

CUs are disabled at WGP granularity (pairs). Disabling CU 6 also disables CU 7 in the same WGP. Format: amdgpu.disable_cu=SE.SH.WGP-pair (comma-separated).

WGP 0 = CU 0,1   (stock active)    — disable_cu=X.Y.0
WGP 1 = CU 2,3   (stock active)    — disable_cu=X.Y.1
WGP 2 = CU 4,5   (stock active)    — disable_cu=X.Y.2
WGP 3 = CU 6,7   (unlocked — test) — disable_cu=X.Y.3
WGP 4 = CU 8,9   (unlocked — test) — disable_cu=X.Y.4

Format: amdgpu.disable_cu=SE.SH.WGP-pair (comma-separated, added to /etc/modprobe.d/bc250-40cu.conf).

# Mask WGP pair 3 on SE0 SH0 -> 38 CUs
options amdgpu bc250_cc_write_mode=3 disable_cu=0.0.3

# Mask WGP pair 4 across all shader arrays -> 32 CUs
options amdgpu bc250_cc_write_mode=3 disable_cu=0.0.4,0.1.4,1.0.4,1.1.4

Bazzite: rpm-ostree kargs --append="amdgpu.disable_cu=X.Y.Z"

CachyOS/Arch: Add to /etc/modprobe.d/bc250-40cu.conf and run sudo mkinitcpio -P (big_trov).

Disabling

If using the duggasco kernel patch:

cd bc250-40cu-unlock
sudo ./scripts/bc250-enable-40cu.sh disable   # removes config, reboots to 24 CU
sudo ./scripts/bc250-enable-40cu.sh restore   # restores original amdgpu module

If using the live-manager: Open the TUI and press t (Restore factory WGPs), or:

cd bc250-cu-live-manager
sudo ./bc250-cu-live-manager.sh stock-dispatch  # restores factory 24 CU layout

40 CU Crash Behavior (big_trov, codyrainy, cralant, May 2026)

Three distinct crash modes exist when pushing 40 CU limits:

2400 MHz at 40 CU consistently causes OCP hard lockup across multiple boards regardless of cooling (big_trov, codyrainy, cralant). One user with AIO cooling reported 2400 MHz at 1120 mV stable (needs >1100 mV or loses FPS; crashes at 1050 mV). Higher CPU overclock lowers the GPU voltage threshold for hard lock -- this is a system-wide power limit, not GPU-specific (big_trov, hojnikb). Defective CUs can individually clock to 2600 MHz -- the defect is NOT clock capability, likely a global OCP/VRM limit. VRM temps are the hidden bottleneck; thermal adhesive tape is insufficient for VRM cooling (capt.cat_13).

Additional OCP findings (late May 2026): Above ~1850-2200 MHz (varies by board), a secondary power limit is tripped causing hard lock where even reset and power buttons fail (big_trov). This is distinct from the voltage ceiling — it's a system-level power limit. A shunt mod may be needed to bypass it (big_trov, May 2026). At 2300 MHz, only ~1025 mV is passable for Superposition on some boards; any higher voltage causes hard lock, any lower causes freeze but remains resettable (big_trov, May 2026).

PS5 40 CU Patch Confirmed

The BC-250 40 CU unlock patch (bc250-40cu-amdgpu.patch) also works on PS5 Linux (gennro, via PS5 Linux Discord, May 2026). The jump from 36 CU to 40 CU on PS5 gives approximately 4% more benchmark score. Note: the PS5 hypervisor still runs during Linux, which may limit performance compared to BC-250 results.

CPU Core Unlock (Jul-Aug 2026 — FUNCTIONAL)

The BC-250 has 6 active Zen 2 CPU cores; the disabled cores are believed to be software/firmware-blocked, not physically fused off. As of late July 2026, functional unlocks now exist via multiple approaches:

How the unlock works (porocyon, Jul 30 2026): The Python script sends a mailbox message to the SMN/PSP (Platform Security Processor) through PCIe, which makes the PSP unlock all cores on the next boot. This is entirely OS-independent — the same mechanism works on any OS. The exploit bypasses the security check and writes an arbitrary bitmask to the core presence register.

Alternate bitmasks (0xcats, Jul 30 2026): The write primitive is not limited to 0xFF. 0xcats tested writing other bitmasks: 0x7F (enables core 3, disables core 7), 0xF7 (enables core 7, disables core 3). This means 7 out of 8 core unlocks are possible on boards where one specific core is defective — the interconnect to cache may be wrong on that core. Not all boards have the same bad core.

Non-0x77 core masks (fforduck, Jul 30 2026): fforduck tested a board with core mask 0x7B (instead of the standard 0x77). The Python script was edited to target this mask and all 8 cores work correctly. If your board has a non-standard disabled-core layout, the script can be modified to match.

Option 1: Patched BIOS (Permanent) — RescueMei/BC250-DXE-SMU-Core-Unlock ↗

Option 2: EFI Shim (Semi-Permanent, No BIOS Modification) — Hexxeh/bc250-efi-core-unlock ↗

Option 3: Python Script (rw-r-r-0644) — rw-r-r-0644/bc250-core-unlock ↗

Option 4: SMU Mailbox 0x98 Tool (gabriwar, Aug 2026) — GabriWar/bc250-core-cu-unlock ↗

Quick start (unlock + verify):

git clone https://github.com/GabriWar/bc250-core-cu-unlock
cd bc250-core-cu-unlock

sudo ./bc250-8core-unlock.sh status     # show current core mask (factory 0x77 = 6 cores)
sudo ./bc250-8core-unlock.sh apply      # unlock now (then: sudo reboot — warm reset preserves it)
./test-cores.sh          # per-core health sweep, 20s/core (~3 min)
./test-cores.sh 60       # longer, more thorough sweep
sudo ./bc250-8core-unlock.sh install    # persist across cold boots via systemd unit

Requires stress-ng and 8 cores already visible (run the unlock first). Interpretation: failed > 0 on any core → that core produces WRONG results, do not use; one core far below the median → marginal silicon, re-test at stock clocks; spread within ~1% → normal binning.

Option 5: movacx/bc250-control-center (Aug 2026) — movacx/bc250-control-center ↗

Option 6: SteamOS Real Toolkit (Aug 2026) — rpf16rj/bc250-steamos-real-toolkit ↗

8-core GPU metrics fix options (Aug 2026):

8-core ACPI fix required after unlock (Aug 2026): The community ACPI fix (bc250-acpi-fix) declares one processor object per thread, and the 6-core tables stop at C00B (12 threads). Once all 8 cores are active you have 16 threads, so CPUs 12–15 get no cpuidle states at all — they cannot enter any C-state and burn power at idle. mendesrr/bc250-acpi-fix-updated-8c ↗ rebuilt the tables to extend the declarations to C00F (16 threads). The gabriwar tool wraps this in bc250-acpi-fix.sh (status/install/revert), which fetches the 8-core SSDTs, backs up your tables and rebuilds the initramfs (Arch/CachyOS/mkinitcpio). For Bazzite/SteamOS, follow the README in the source repo. Verify with cpupower idle-info or check for missing C-states.

Field reports (Aug 2026):

8 Cores ≠ 6 Cores: The Full Process (Aug 2026)

Unlocking to 8 cores is not a drop-in change — the board, ACPI, governor and OC all need rework. The community consensus process that emerged this week:

1. Test your cores first, then flash. The BIOS mod is now the dominant method (rescuemei: "I just use a bios mod for unlocking them on my bc250s since I know their cores are good", Aug 13 2026), but it is mandatory to verify the unlocked cores before committing to a flash: "TEST YOUR CORES WITH @rw-r-r-0644'S SCRIPT BEFORE FLASHING THE BIOS TO ENABLE THEM" (rescuemei, Aug 13 2026). The BIOS mod "does the same exact unlock and warm reset, just faster and at boot" (rescuemei, Aug 13 2026), and "only enable the 8 core unlock if your system is stable at 8 through the script" (rescuemei, Aug 13 2026). If the extra cores are defective and you flashed the BIOS anyway, you must recover via external programmer.

2. Apply the ACPI fix — and accept a small FPS cost. The 6-core ACPI tables stop at 12 threads (C00B); 8 cores = 16 threads, so CPUs 12–15 get no cpuidle states (see the ACPI section above). Several users report the ACPI fix has a measurable framerate hit: dbkretro (Aug 10 2026): "I get a perf drop from solid 60fps to 52-55fps on RE4 with ACPI on in the BIOS, same as when I tried it in software" and "Your mileage may vary with ACPI, at least a few of us have found it can hit the frame rate" (Aug 13 2026). dizzey0709 (Aug 10 2026) noted reduced FPS in GPU-intensive tasks after enabling 8 cores + ACPI together, and wondered if ACPI's clock management conflicts with the governor — no consensus yet. The BIOS-built-in ACPI fix uses the same tables as the software one (rescuemei: "Yeh, it's inserting the same acpi tables", Aug 10 2026), so the FPS behavior is equivalent.

3. Re-tune the CPU OC. The unlocked 8-core config changes load-line droop, thermals and the shared CPU/GPU power budget. seb061492 (Aug 4 2026) found an OC stable at 6 cores (4 GHz) crashes in Unigine at 8 cores — even at 3.5 GHz — unless the governor/SMU service is disabled entirely (likely a marginal unlocked core, baalah: "bad cpu core"). Typical working 8-core configs this week: 3.5–3.85 GHz CPU (sho.ta: 8 cores @ 3.85 GHz 1150 mV for RDR2) vs 4.0–4.1 GHz common on 6 cores. mitchthepreacher (Aug 13 2026): OCCT's Combined setting (CPU+GPU together) throws errors at CPU 4 GHz — "I should probably back off... Don't seem to have any issues in games." Stress test the combined load, not just single-core.

4. Expect +10-12°C and higher power draw. felingreenleaf (Aug 12 2026) measured MK1 at 54–58 FPS on 6 cores vs 59–60 FPS on 8 cores — "about a 10-12C difference" in temps. buzzynoob (Aug 6 2026): "Since the new core unlocks the power draw has increased". Factor both into your cooling and PSU margin.

5. Re-enable GPU metrics via the fix-freq governor option or the kernel patch (see the metrics fix options above and 06-gpu-governor.md) — the 8-core per-core SMU arrays displace GfxclkFrequency, so pp_dpm_sclk shows nonsense until fixed.

6. Defective-cores contingency. Not every board unlocks cleanly: fforduck (Aug 3 2026) has cores 4 and 5 that pass stress tests yet misbehave in some games — he pins Steam to use all cores except 4 and 5 (partial masks are supported, see alternate bitmasks above). If a single core is bad, the 7-of-8 mask (0x7F/0xF7) is a valid target.

Why this is not a "just unlock" switch: the 6-core vs 8-core difference is not only the two extra cores — ACPI cpuidle coverage, GPU telemetry layout, load-line response and thermal envelope all change. Users who enable 8 cores without the ACPI fix burn power at idle on CPUs 12–15; users who skip the metrics fix get wrong GPU clock readings; users who skip re-tuning risk instability at old OC voltages.

Auto-activation script (qwert9811, Jul 2026): A community script checks for 8 active cores on cold boot, runs the unlock Python script if needed, and reboots (with a reboot counter to prevent infinite loops). Works on CachyOS desktop.

Game mode shortcut (dbkretro, Aug 1 2026): The unlock script can be added as a non-Steam game in game mode — tap the icon, it runs the unlock steps and reboots. Requires sudoers entry to avoid password prompts.

Silicon lottery (0xcats, Jul 30 2026): Of 5 boards tested, 1 could not reliably boot with all 8 cores (crashes or hangs during POST). That board had core mask 0x7E — core 0 defective. Roughly 80% success rate in this small sample. Boards that fail POST with the unlock typically need an external programmer to recover.

Background: duggasco and mrfrakes previously decompiled and extracted bootrom and understood how the PSP (Platform Security Processor) checks and initializes cores from fuses. The working theory was that cores are controlled by a ROM array written during manufacturing rather than physically fused off — now validated by the working unlocks. Early speculation: unlocking BC-250 cores could theoretically apply to other low-end Ryzen CPUs with disabled cores, but that's uncharted territory.

jwagnervaz BIOS Rev Eng (Jul 09-11, 2026): Another independent modder is reverse engineering a custom BIOS for the BC-250:

VCN unlock discussion (Jul 30 2026): thelamer proposed using the same register exploit for VCN (video codec) hardware decode — VCN feature version: 0, firmware version: 0x00000000 suggests the hardware is present but disabled. yrouel86 notes this would still need the firmware blob, and it would most likely need to be signed. VCN unlock remains an open research question.

Credits: RescueMei (@The Mei™, patched BIOS, test-before-flash guidance), Hexxeh (EFI shim), qwert9811 (auto-activation script), rw-r-r-0644 (Python unlock script), 0xcats (alternate bitmask testing), fforduck (0x7B mask testing, partial-mask gaming workaround), keroppl_wizard (8-core metrics patch), dbkretro (game mode shortcut, ACPI FPS cost report), jwagnervaz (independent BIOS rev eng, 4700S testing), yrouel86 (verification guidance), zedan015 (non-standard core layout testing), porocyon (SMN/PSP mechanism explanation), dizzey0709 (hard shutdown behavior), gabriwar (SMU mailbox 0x98 unlock tool), filippor (fix-freq governor option), punsh (fix-freq discovery), higorprado (8-core SMU metrics layout), mendesrr (8-core ACPI tables), movacx (control center), rpf16rj (SteamOS toolkit), luciud (SteamOS persistence report), skcanss (unlock persistence testing), buzzynoob (power draw), alexxxor_ (BIOS hash mismatch), midlifediy (EFI-vs-BIOS observation), j0shm1lls (bad-core report), vadym557 (boot failure with bad cores), felingreenleaf (8-core temp delta), seb061492 (8-core OC regression report), mitchthepreacher (combined stress report), sho.ta (8-core RDR2 config).

SMU Firmware Reverse Engineering (Jul 2026)

The bc250-collective/amd_smu_reverse_engineering ↗ project is reverse engineering the SMU (System Management Unit) firmware — the tiny microcontroller on the APU die that handles power, voltage, frequency, and thermal management. The SMU is a PS5-customized variant (not the standard AMD SMU), which is why standard tools like ZenStates-Core don't work.

Key findings so far:

Why this matters: Unlocking SMU commands could enable CPU overclocking (currently limited to ~4 GHz via bc250_smu_oc), proper sleep/suspend mode, and finer power management. ded811 is actively working on sleep mode through SMU analysis. keroppl_wizard is using AI-assisted BIOS ROM analysis.

Credits: ded811 (SMU research, sleep mode), big_trov (repo discovery), keroppl_wizard (BIOS ROM analysis), keyboardspecialist (SMU-FINDINGS.md).

40 CU Kernel Build Warnings

Credits

duggasco (research, repo), filippor (independent testing, ignore_cu_harvest), scallion_9883 (benchmarks), vinnijs.dev (bc250-cu-live-manager), faithy2386 (P4.00 BIOS discovery, flashrom testing), meee (CU artifact detection), pm_me_kitsunemimi (game-based CU testing), Claude/Codex (SPI register discovery), kilrah (disable_cu masking), hojnikb (harvest maps), koloses (bad CU testing), essdee4336 (thermal), big_trov (stable verify), codyrainy (build test).
